Commercial Electrical Enclosure C-Box Series: C-Box  Screw Cover without Knockouts Series Enclosures - NEMA 1







                           C-Box  Screw Cover without Knockouts Series Enclosures - NEMA 1



Application:

  • Designed for general purpose indoor commercial use as a junction, pull or switch box.

Standards:

  • UL-50 Type 1

  • CSA Type 1

  • Complies with

    • NEMA Type 1

    • IEC 60529, IP20

Construction:

  • Formed and spot welded from 16, 14 or 12 gauge steel depending on size.

  • Flat steel covers fastened with plated steel screws.

  • Keyhole slots permit cover to be lifted off without removing screws entirely.

  • Through holes in back for wall mounting.

  • Grounding location embossed in body.

Finish:

  • Enclosure and cover are finished in ANSI 61 gray powder coating.

Accessories:

  • N/A








Part No.

Overall Dimensions

Mtg. Centers



Ship Wt.
lbs.

A

B

C

D

E

F

G

H

EID-CS443

4

4

3

2

3

0.88

0.5

0.28

2

EID-CS663

6

6

3

3

5

1.50

0.5

0.28

3

EID-CS863

8

6

3

5

5

1.50

0.5

0.28

3

EID-CS16143

16

14

3

13

13

1.50

0.5

0.28

12

EID-CS18143

18

14

3

15

13

1.50

0.5

0.28

13

EID-CS20143

20

14

3

17

13

1.50

0.5

0.28

13

EID-CS444

4

4

4

2

3

0.88

0.5

0.28

2

EID-CS644

6

4

4

3

3

1.50

0.5

0.28

3

EID-CS664

6

6

4

3

5

1.50

0.5

0.28

3

EID-CS864

8

6

4

5

5

1.50

0.5

0.28

5

EID-CS884

8

8

4

5

7

1.50

0.5

0.28

5

EID-CS1084

10

8

4

7

7

1.50

0.5

0.28

6

EID-CS10104

10

10

4

7

9

1.50

0.5

0.28

6

EID-CS1284

12

8

4

9

7

1.50

0.5

0.28

7

EID-CS12104

12

10

4

9

9

1.50

0.5

0.28

8

EID-CS12124

12

12

4

9

11

1.50

0.5

0.28

9

EID-CS16124

16

12

4

13

11

1.50

0.5

0.28

12

EID-CS18124

18

12

4

15

11

1.50

0.5

0.28

12

EID-CS18184

18

18

4

15

17

1.50

0.5

0.28

16

EID-CS24244

24

24

4

21

23

1.50

0.5

0.28

33

EID-CS666

6

6

6

3

5

1.50

0.5

0.28

4

EID-CS886

8

8

6

5

7

1.50

0.5

0.28

6

EID-CS1086

10

8

6

7

7

1.50

0.5

0.28

7

EID-CS10106

10

10

6

7

9

1.50

0.5

0.28

8

EID-CS12106

12

10

6

9

9

1.50

0.5

0.28

8

EID-CS12126

12

12

6

9

11

1.50

0.5

0.28

9

EID-CS16126

16

12

6

13

11

1.50

0.5

0.28

13

EID-CS16166

16

16

6

13

15

1.50

0.5

0.28

16

EID-CS18126

18

12

6

15

11

1.50

0.5

0.28

14

EID-CS18186

18

18

6

15

17

1.50

0.5

0.28

19

EID-CS24186

24

18

6

21

17

1.50

0.5

0.28

26

EID-CS24246

24

24

6

21

22.5

1.50

0.75

0.44

37

EID-CS30246

30

24

6

27

22.5

1.50

0.75

0.44

45

EID-CS36246

36

24

6

33

22.5

1.50

0.75

0.44

57

EID-CS36366

36

36

6

33

34.5

1.50

0.75

0.44

70

EID-CS12128

12

12

8

9

11

1.50

0.5

0.28

12

EID-CS16168

16

16

8

13

15

1.50

0.5

0.28

18

EID-CS18188

18

18

8

15

17

1.50

0.5

0.28

21

EID-CS24248

24

24

8

21

22.5

1.50

0.75

0.44

42

EID-CS36248

36

24

8

33

22.5

1.50

0.75

0.44

65

EID-CS202010

20

20

10

17

19

1.50

0.75

0.44

35

EID-CS242410

24

24

10

21

22.5

1.50

0.5

0.28

49

EID-CS302010

30

20

10

27

18.5

1.50

0.75

0.44

55

EID-CS362410

36

24

10

33

22.5

1.50

0.75

0.44

70

EID-CS363612

36

36

12

33

34.5

1.50

0.75

0.44

88



  •
