Industrial Electrical Enclosure EID-1418 Series: EID-1418 N4 Freestanding Single Door with Quarter Turn Latches Series Enclosures - NEMA 4

             EID-1418 N4 Freestanding Single Door with Quarter Turn Latches Series Enclosures - NEMA 4

Application:

• Designed to house electrical, electronic, hydraulic or pneumatic controls with provision for panel mounting or rack mounting of equipment.

• Provides protection where equipment may be hosed down or otherwise be very wet, or in specific applications where corrosion is a serious problem.

• A variety of inner panels, rack mounting rails and swing out frames are available to provide flexibility in mounting arrangements.

Standards:

• UL 508 Type 3R, 4 and 12

• CSA Type 3R, 4 and 12

• Complies with

  • NEMA Type 3R, 4, 12 and 3

  • IEC 60529, IP54

Construction:

• Formed 12 gauge steel.

• Smooth, continuously welded seams without knockouts, cutouts or holes.

• Lifting eyes provide for easy enclosure handling.

• Doors are supported with heavy gauge continuous hinges.

• Doors are secured quarter turn latches.

• Seamless poured-in place gasket.

• Provision for light kit mounting.

• Mounting channels are welded on the inside of the enclosure for mounting of optional inner panels or rack equipment rails.

• A grounding stud is provided in the enclosure and a bonding stud is provided on the door.

Finish:

• Cover and enclosure are finished in recoatable smooth ANSI 61 gray powder coating.

• Optional inner panels are available in white powder coating, or unpainted galvanized steel.

Accessories:

• Air conditioners

• Breather kits

• Door Stop Kits

• Drip Shield Kits

• Enclosure Stabilizers

• Filter fans

• Gland Plates

• Heaters

• Inner Panels

• Light Kit

• Panel Rails

• Swing Frames

• Thermostats

• Window kits

1 Refers to optional full height/full width panels. Depth panels and half height width panels are also available.

  ^•
