Corrosion Resistant Enclosure EID-1418 N4 Series: EID-1418N4 Aluminum Continuous Hinge, Clamped Cover Series Enclosures - NEMA 4

                          EID-1418N4 Aluminum Continuous Hinge, Clamped Cover Series Enclosures - NEMA 4

Application:

• Designed for use as instrument enclosures, electric, hydraulic or pneumatic control housings, electrical junction boxes or terminal wiring enclosures.

• Provides protection where equipment may be hosed down or otherwise be very wet, or in specific applications where corrosion may be a problem.

Standards:

• UL 508 Type 4 and 12

• CSA Type 4 and 12

• Complies with

  • NEMA Type 4, 12 and 13

  • JIC EGP-1-1967

  • IEC 60529, IP66

Construction:

• Formed from 0.081" (Body) / 0.100" (Door) Type 5052 H-32 aluminum.

• Smooth, continuously welded seams without knockouts, cutouts or holes.

• Door and body stiffeners are provided in the larger enclosures for extra rigidity.

• Welded brackets provide for enclosure mounting.

• Formed lip on door and enclosure excludes flowing liquids and contaminants.

• Aluminum continuous hinge on door may be removed by pulling the alum­inum hinge pin.

• Door is secured with easily operated aluminum clamps.

• Provision for padlocking.

• Seamless poured-in place gasket.

• A removable 12 gauge inner panel is included.

• Collar studs are provided for mount­ing inner panels.

• A bonding stud is provided on the door and a grounding stud is provided in the enclosure.

• A literature pocket is provided for the inside of the door.

Finish:

• Cover and enclosure are natural unfinished aluminum.

• Removable inner panel is finished in white powder coating

Accessories:

• Additional inner panels

• Breather kits

• Door Clamping Hardware

• Door Stop Kits

• Heaters

• Lock Kit

• Terminal kit assemblies

• Thermostats

• Window kits

  ^•
