Our BNC Connectors are miniature, light-weight and durable units suitable for a wide range of applications. Mating is by a 2-stud bayonet lock.

ELECTRICAL SPECIFICATIONS
Nominal Impedance:     50 Ohms
Frequency Range:                      0-4 GHz
Voltage Rating:           AC 500V
Withstanding Voltage:  1500 Volts RMS
Insulation Resistance:   5000 Mega ohms Min.
Temperature Range:    67' to 390' F
Vibration:        Mil. Std. 202 Method 204
Shock:                        Mil. Std. 202 Method 202
Moisture Resistance:      Mil. Std. 202 Method 105
MATERIALS
Body Housing Brass
Male Contact Brass, Gold Plated
Female Contact Brass, Gold Plated Crimp
Ferrule Copper
Gasket Silicone Rubber
Dielectric Delrin, Teflon or PBT
